Small Pixel Pitch Indoor Screen P1.875 LED Display High Refresh
Advertising Meeting Screen
(1) Description of Indoor Fixed Ultra High Definition Advertising
LED Display:
1) UHD video wall panel 600mm x 300.7mm cabinet indoor led video
wall.
2) DOUBLE backup system design to ensure foolproof during use.
3) Flat splicing, support fine adjusting.
4) The module uses high-quality floating connectors, foolproof
design to avoid reverse installation.
(2) Quick Detail:
Pixel Pitch: 1.875mm
LED configuration: SMD1415
Module Size: 150(W)*168.75(H)mm
Refresh rate: 3840Hz.
Cabinet Size: 600(W)*337.5(H)*60(D)mm
Maintenance type: Front maintenance.
(3) Specifications:
| Module Parameter |
| 1 | Item | UHD1.8 |
| 2 | Pixel Pitch | 1.875mm |
| 3 | Pixel density | 284444dots/㎡ |
| 4 | LED configuration | SMD1415 |
| 5 | Module size | 150(W)×168.75(H)×2(D)mm |
| 6 | Module resolution | 80(W)x90(H) |
| 7 | Module weight | 0.3Kg |
| 8 | Scanning Mode | 1/40 |
| 9 | IC model | FM6353 |
| Cabinet Parameter |
| 1 | Cabinet resolution | 320(W)x180(H) |
| 2 | Cabinet size | 600(W)×337.5(H)×60(D)mm |
| 3 | Cabinet material | Die Casting Aluminum |
| 4 | Cabinet weight | 5.5kg |
| 5 | Module number | 4*2 |
| 6 | Brightness | 600cd/㎡ |
| 7 | Viewing angle | 160°(horz.), 160° (vert.) |
| 8 | Optimal View Distance | 1.8m-18m |
| 9 | Gray scale | 14(bit) |
| 10 | Max Power Consumption | 600W/㎡ |
| 11 | Avg Power Consumption | 200W/㎡ |
| 12 | Work Voltage | AC200-264V |
| 13 | Frame Frequency | 60Hz |
| 14 | Refresh rate | 3840Hz |
| 15 | Operation System | Win7&XP |
| 16 | Control Mode | Synchronization with PC |
| 17 | Operating Temperature | ( -40℃～+ 60℃ ) |
| 18 | IP Rating(Front/Rear) | IP31 |
| 19 | maintenance type | Front maintenance |
| 20 | Life Span | 100,000Hours |
Notes:
1. Open the package, check the product carefully, and handle it
with care to avoid damage to the product.
2. Regular cleaning and maintenance: After the LED display has been
used for a long time, more dust and traces of rain will accumulate
on the screen, which requires regular and timely cleaning to
prevent the viewing effect from being affected;
3. If cleaning the surface of the module, please use a soft brush
to wipe it gently. It is forbidden to use any liquid substances to
clean the surface of the LED module, otherwise the LED lamp beads
may be damaged;
4. Wipe correctly: The surface of the large screen of the LED
display can be wiped with alcohol, or dusted with a brush or a
vacuum cleaner. It cannot be wiped directly with a damp cloth.
Application:
It is widely used in conference rooms, monitoring rooms, stadiums,
airports, shopping malls, TV stations and other important places.
FAQ:
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed
samples are acceptable.
Q2. How can we guarantee quality?
A: Always a pre-production sample before mass production; Always
final Inspection before shipment.
Q3.What can you buy from us?
A: LED Display,LED Screen,LED Billboard,Transparent LED Video
Wall,Stadium LED Screen etc.
Q4. Why should you buy from us not from other suppliers?
A: Factory-direct price, CAD Drawing support, Globule service
centre.
Q5. What services can we provide?
A: Accepted Delivery Terms:
FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express
Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit
Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,French,Korean,Italian etc.
