    Indoor Fixed Video Wall Panel P1.25 LED Advertising Screen For Control Room

    Ask Lasest Price
    Brand Name : Showtechled
    Model Number : HD Series-P1.538
    Certification : CE/FCC/ETL/EMC
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 10000sqm/month
    Delivery Time : 15-25 work days
    • Product Details
    • Company Profile

    Indoor Fixed Video Wall Panel P1.25 LED Advertising Screen For Control Room


    HD Series -- Indoor Fixed Video Wall Panel P1.25 LED Advertising Screen In Control Room Of Shopping Mall Retail Store


    (1) Description of Indoor Fixed Video Wall Panel P1.25 LED Advertising Screen:

    1. Die-cast aluminum, ultra-light, ultra-thin; Cabinet size: 640mm*480mm*50mm, a single cabinet weighs only 6KG

    2. Wide Viewing Angle: ViewingAngle:160°(horz.),160°(vert.)

    3. Excellent visual effect: low brightness, high grayscale, high refresh rate, stable dynamic display effect, and more comfortable visual experience.

    4. Front maintenance, front installation: The module has magnets to make front maintenance easier.

    5. A variety of installation methods: HD series installation is easier to use, and the scope of use is wider.


    (2) Quick Detail:

    Pixel Pitch:1.25mm

    Cabinet Size:640*480mm

    Refresh rate: 3840Hz.

    Wide viewing angle :160°(horz.), 160° (vert.).

    Maintenance type:Front maintenance.

    Life Span:100,000Hours


    (3) Specifications:

    Module Detail
    1ItemHD1.5
    2Pixel Pitch1.25mm
    3Pixel density

    640000dots/㎡

    4LED configurationSMD1010
    5Module size320(W)×160(H)×12(D)mm
    6Resolution of Module256(W)*128(H)
    7Module weight0.5Kg
    8Scanning Mode1/64
    9IC model

    ICN2153

    Cabinet Detail
    1Resolution of Cabinet512(W)*384(H)
    2Cabinet size640(W)*480(H)*50(D)mm
    3Cabinet materialDie casting mg alloy
    4Cabinet weight6kg
    5Module number2*3
    6Brightness600cd/㎡
    7Viewing angle160°(hor.), 160° (vert.)
    8Optimal View Distance1.25m-12.5m
    9Gray scale14(bit)
    10Max. Power Consumption580W/㎡
    11Avg. Power Consumption193W/㎡
    12Work VoltageAC190-264V
    13Frame Frequency60Hz
    14Refresh rate3840Hz
    15

    Operation System

    Win7&XP

    16Control ModeSynchronization with PC
    17Operating Temperature( -40℃~+ 50℃ )
    18IP Rating(Front/Rear)IP31
    19maintenance typeFront maintenance
    20Life Span100,000Hours

    Notes:

    · Open the package, check the product carefully, and handle it with care to avoid damage to the product.

    · Be sure to connect the wires exactly, do not connect the wrong wires.

    · Do not expose the copper wire outside the power hole to avoid short cut or electric shock.

    · When installing and disassembling the product, please install it carefully to avoid damaging the product, and please disconnect the power supply to avoid electric shock.


    Application:

    Widely used in buildings, factories, conference rooms, monitoring rooms, stadiums, airports, shopping malls, restaurants, hospitals and other places.


    FAQ:

    Q1. How can i place an order?

    A: Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with WhatsApp/email /phone, in case of any delays.


    Q2. What kind of display do we provide?

    A: We have indoor fixed led display /Small pixel pitch led display/Flexible soft led display/Naked eye 3D led display/Outdoor Mesh Screen/Transparent led display/Billboard led display/Outdoor fixed led display/Front service led display/Energy saving led display/Stadium led display /rental led display/ Advertising led display for you choose.


    Q3. What about the lead time for an order?

    A: Always: 15-35 days, as your order quantity, sometimes we have stock, can ship out within 7 days
