    P10 Facade LED Screen

    Ask Lasest Price
    Brand Name : Showtechled
    Model Number : C Series-C1010
    Certification : CE/FCC/ETL/EMC
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 10000sqm/month
    Delivery Time : 15-25 work days
    • Product Details
    • Company Profile

    P10 Facade LED Screen


    C Series -- Showtechled Waterproof High Transparency Outdoor Fixed Media Fasade Advertising LED Screen HD Mesh Display

    (1) Description of Outdoor Waterproof High Transparency Fixed Media Fasade Advertising LED Screen:

    1. Our outdoor mesh screen is lighter, cabinet weight only 21Kg. and the wind load is much smaller.
    2. The LED mesh screen breaks through the many restrictions on the building and the wall of the conventional LED display, making the project more flexible and more choices.
    3. The cabinet is lighted and easy for transportation and installation, which can save much cost for steel structure.

    (2) Quick Detail:

    ● Cabinet size: 1000(W)×1000(H)×80(D)mm

    ● Cabinet weight: 19kg

    ● Transparency Rate: 42%

    ● Refresh rate:3840Hz

    ● Maintenance type: Front / Back Maintenance

    ● Life Span: 100,000Hours


    (3) Specifications:

    Module Parameter
    1ItemC1010
    2Pixel Pitch10.4x10.4mm(H*V)
    3Pixel density9216dots/㎡
    4LED configurationSMD3535
    5Module size500(W)×125(H)×25(D)mm
    6Module resolution48(W)x12(H)
    7Scanning Mode1/2 Scan
    Cabinet Parameter
    1Cabinet resolution96(W)x96(H)
    2Cabinet size1000(W)×1000(H)×80(D)mm
    3Cabinet weight19kg
    4Cabinet marerialAluminum
    5Transparency Rate42%
    6Brightness6000cd/㎡
    7Viewing angle160°(horz.), 160° (vert.)
    8Optimal View Distance12m
    9Gray scale14(bit)
    10Max Power Consumption850W/㎡
    11Avg Power Consumption250W/㎡
    12Work VoltageAV190-260V
    13Frame Frequency60Hz
    14Refresh rate3840Hz
    15Operation SystemWin7&XP
    16Control ModeSynchronization with PC
    17Operating Temperature( -40℃~+60℃ )
    18IP Rating(Front/Rear)IP65/IP65
    19Installation / maintenance typeFront / Back installation
    Front / Back maintenance
    20Life Span100,000 Hours

    Notices:

    • Check the circuit and switch of the LED screen, keep the switch dry, and avoid leakage and electric shock accidents.
    • Regularly check whether the power and signal lines are broken or bitten.
    • The power supply should be stable, and the grounding protection should be good. Regularly check the reliability of the lightning rod and grounding system.
    • Do not expose the copper wire outside the power terminal hole to avoid short circuit or electric shock.
    • Be sure to connect the wires correctly, do not connect the wrong wires.

    Application:

    Widely used for outdoor squares, stadiums, hotels, hospitals, schools, shopping malls, supermarkets, etc.


    FAQ:
    Q1: What is your MOQ?
    A: Any quantity is acceptable for your order. And the price is negotiable for large quantity.

    Q2: When will you make the delivery?
    A: We can make the delivery within 7-15 working days for the sample and 15-30days for the led finished screen according to the size and quantities of your order.

    Q3: What technical supports can you offer?
    A: We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. we can send an engineer team to the country of the customer to instruct the installation.
