    Module LED P10 Smd Full Color Outdoor Transparent LED Screen High Refresh Rate

    Ask Lasest Price
    Brand Name : Showtechled
    Model Number : T-Pro P10.41
    Certification : CE/FCC/ETL/EMC
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 10000sqm/month
    Delivery Time : 15-25 work days
    • Product Details
    • Company Profile

    Module LED P10 Smd Full Color Outdoor Transparent LED Screen High Refresh Rate


    T-Pro Series -- Indoor and Outdoor Rental LED Display Waterproof High Refresh Rate Transparent Screen:

    (1) Description of Rental LED Display:
    1. High transparency: T- pro series product has high transparency of 50%-70%;
    2. Front & rear installation and maintenance: this product can be installed in a variety of outdoor environments because it can be either front or rear installed and maintained; Modules, receiving cards, power supply, cabinet, all the parts can be front maintained, not merely modules;
    3. Lightweight : Frame materials is Die-casting aluminum , only 7.5kg/pc.;
    4. High refresh rate: Refresh can reach 3840Hz;
    5. Quick installation and maintenance, quick lock for quick installation and connection, save time, front/rear maintenance, fast maintenance.


    (2) Detail:

    Brightness:5000cd/㎡

    Refresh rate: 3840Hz optional

    Viewing angle:160°(horz.), 160° (vert.)

    Work Voltage:AC190-264V

    Maintenance:Front/Rear maintenance

    Life Span:100,000Hours

    Warranty :2 Year


    (3) Specifications:

    Module Parameter
    1ItemT1010
    2Pixel Pitch10.41x10.41mm(H*V)
    3Pixel density9216dots/㎡
    4LED configurationSMD 3535
    5Module size500(W)×125(H)×15(D)mm
    6Module resolution48(W)x12(H)
    7Scanning Mode1/2 Scan
    Cabinet Parameter
    1Cabinet resolution96(W)x48(H)
    2Cabinet size1000(W)×500(H)×70(D)mm
    3Cabinet weight7.5kg
    4Cabinet marerialDie-Cast Aluminum
    5Transparency Rate40%
    6Brightness5000cd/㎡
    7Viewing angle160°(horz.), 160° (vert.)
    8Optimal View Distance12m
    9Gray scale14(bit)
    10Max Power Consumption850W/㎡
    11Avg Power Consumption250W/㎡
    12Work VoltageAV190-260V
    13Frame Frequency60Hz
    14Refresh rate3840Hz
    15Operation SystemWin7&XP
    16Control ModeSynchronization with PC
    17Operating Temperature( -40℃~+60℃ )
    18IP Rating(Front/Rear)IP65/IP65
    19Installation / maintenance typeFront / Back installation
    Front / Back maintenance
    20Life Span100,000Hours

    Notices:

    · Open the package, check the product carefully, and handle it with care to avoid damaging the product.

    · Be sure to connect the wires correctly, do not connect the wrong wires.

    · Do not expose the copper wire outside the power terminal hole to avoid short circuit or electric shock.



    Application:Widely used in outdoor squares, stadiums, hotels, hospitals, schools, shopping malls, supermarkets, bars and other stage activities.



    FAQ:

    Q1. Can I have a sample order for led display?

    A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.


    Q2. What about the lead time?

    A: 15-25 days for Sample preparing ,25-35 working days for mass production.


    Q3. Do you have any MOQ limit for led display order?

    A: Low MOQ, 1pc for sample checking is available.


    Q4. How do you ship the goods and how long does it take to arrive?

    A: Ship by DHL, UPS, FedEx or TNT. It takes 5-15 days to arrive. Airline and sea shipping also optional.


    Q5. How to proceed an order for led display?

    A: Firstly, let us know your requirements or application.

    Secondly, We quote according to your requirements or our suggestions.

    Thirdly, customer confirms the samples and places deposit for formal order.

    Fourth, we arrange production and delivery.
