SMD3535 Aluminum Front Maintenance LED Display Light Weight Outdoor Waterproof

    Buy cheap SMD3535 Aluminum Front Maintenance LED Display Light Weight Outdoor Waterproof from wholesalers

    Buy cheap SMD3535 Aluminum Front Maintenance LED Display Light Weight Outdoor Waterproof from wholesalers
    • Buy cheap SMD3535 Aluminum Front Maintenance LED Display Light Weight Outdoor Waterproof from wholesalers
    • Buy cheap SMD3535 Aluminum Front Maintenance LED Display Light Weight Outdoor Waterproof from wholesalers
    • Buy cheap SMD3535 Aluminum Front Maintenance LED Display Light Weight Outdoor Waterproof from wholesalers
    • Buy cheap SMD3535 Aluminum Front Maintenance LED Display Light Weight Outdoor Waterproof from wholesalers

    SMD3535 Aluminum Front Maintenance LED Display Light Weight Outdoor Waterproof

    Ask Lasest Price
    Brand Name : Showtechled
    Model Number : FB Series-FB10.4
    Certification : CE/FCC/ETL/EMC
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 10000sqm/month
    Delivery Time : 15-25 work days
    • Product Details
    • Company Profile

    SMD3535 Aluminum Front Maintenance LED Display Light Weight Outdoor Waterproof


    FB Series -- Outdoor Waterproof Front Maintenance LED Display Right Angle Light Weight LED Screen


    (1) Description of Outdoor Fixed Front Maintenance Front Service Advertising LED Display:

    The cabinet is very lightweighted, only 20KG, standard cabinet size 1000*1000*76mm, the solution can save the transportation and installation cost. Support full front maintenance, Modules, receiving cards, power supply, cabinet, all the parts can be realized front maintenance, not merely modules. The edges of modules and frame are designed to be 45 degrees, it is easier to make right-angled connection. Between screens, right-angled stitching without gaps is realized. This function can perfectly realize glasses-free 3D display for users.


    (2) Quick Detail:

    ● Lightweight Cabinet;

    ● Cabinet materials: Aluminum

    ● Brightness: 6000-6500nits

    ● Refresh rate: 3840Hz

    ● Work Voltage: AC200-240V

    ● Maintenance type: Front or Back Maintenance

    ● Life Span: 100,000Hours

    ● 2 Year Warranty


    (3) Specifications:

    Module Parameter
    1ItemFB10
    2Pixel Pitch10.41mm(H*V)
    3Pixel density9216 dots/㎡
    4LED configurationSMD3535
    5Module size500(W)×250(H)*16(D)mm
    6Module resolution48(W)x24(H)
    7Scanning Mode1/3 Scan
    Cabinet Parameter
    1Cabinet resolution96(W)x96(H)
    2Cabinet size1000(W)×1000(H)×76(D)mm
    3Cabinet materialsAluminum
    4Cabinet weight20kg
    5Brightness6000cd/㎡
    6Viewing angle160°(horz.), 160° (vert.)
    7Optimal View Distance10.4m
    8Gray scale14bit
    9Max Power Consumption750W/㎡
    10Avg Power Consumption250W/㎡
    11Work VoltageAC200-240V
    12Frame Frequency60Hz
    13Refresh rate3840HZ
    14Operation SystemWin7&XP
    15Control ModeSynchronization with PC
    16Operating Temperature( -40℃~+60℃ )
    17IP Rating(Front/Rear)IP65/IP54
    1890° right Angle splicing functionTo do naked eye 3D display
    19Installation / maintenance typeFront / Back installation
    Front / Back maintenance
    20Life Span100,000Hours

    Application:

    Widely used for outdoor squares, stadiums, hotels, hospitals, schools, shopping malls, supermarkets, etc.


    FAQ:

    Q1. How Can you Guarantee Quality?

    A: Seven quality control steps ensure your ordered screens are good.

    Material check by professional workers and machines. 72-hour aging test for whole screen before shipment.


    Q2. May be we will need some samples, what is the lead time of samples and lead time of order?

    A: Always: 15-25 days, as your order quantity, sometimes we have stock, can delivery within 7 days.


    Q3. What services can we provide?

    A: Accepted Delivery Terms: FOB/CFR/CIF/EXW/FAS/FCA/DDP/DDU/Express Delivery;

    Accepted Payment Currency:USD/RMB;

    Accepted Payment Type: T/T,L/C etc.
