FB Series -- Showtechled Outdoor Waterproof 3D Naked Eye LED
Display Commercial Advertising Billboard Wall LED Screen
(1) Description of Outdoor Waterproof 3D Naked Eye LED Display:
The product supports full front maintenance. Modules, receiving
cards, power supply, cabinet, all the parts can be realized front
maintenance, not merely modules. The edges of modules and frame are
designed to be 45 degrees, it is easier to make right-angled
connection. Between screens, right-angled stitching without gaps is
realized. This function can perfectly realize glasses-free 3D
display for users.
(2) Quick Detail:
● Cabinet Weight: 22kg
● LED configuration: DIP346
● Cabinet materials: Aluminum
● Brightness: 7500nits
● Max Power Consumption: 390W/㎡
● Avg Power Consumption: 130W/㎡
● Refresh rate: 3840Hz
● Viewing angle: 120°(horz.), 60° (vert.)
● Work Voltage: AC200-240V
● 90°right Angle splicing function: do naked eye 3D display
● Maintenance type: Front / Back Maintenance
(3) Specifications:
| Module Parameter |
| 1 | Item | FB10D |
| 2 | Pixel Pitch | 10.41mm(H*V) |
| 3 | Pixel density | 9216 dots/㎡ |
| 4 | LED configuration | DIP346 |
| 5 | Module size | 500(W)×250(H)*16(D)mm |
| 6 | Module resolution | 48(W)x24(H) |
| 7 | Scanning Mode | 1/3 Scan |
| Cabinet Parameter |
| 1 | Cabinet resolution | 96(W)x96(H) |
| 2 | Cabinet size | 1000(W)×1000(H)×85(D)mm |
| 3 | Cabinet materials | Aluminum |
| 4 | Cabinet weight | 22kg |
| 5 | Brightness | 7500cd/㎡ |
| 6 | Viewing angle | 120°(horz.), 60° (vert.) |
| 7 | Optimal View Distance | 10.4m |
| 8 | Gray scale | 14bit |
| 9 | Max Power Consumption | 390W/㎡ |
| 10 | Avg Power Consumption | 130W/㎡ |
| 11 | Work Voltage | AC200-240V |
| 12 | Frame Frequency | 60Hz |
| 13 | Refresh rate | 3840HZ |
| 14 | Operation System | Win7&XP |
| 15 | Control Mode | Synchronization with PC |
| 16 | Operating Temperature | ( -40℃～+60℃ ) |
| 17 | IP Rating(Front/Rear) | IP65/IP54 |
| 18 | 90° right Angle splicing function | To do naked eye 3D display |
| 19 | Installation / maintenance type | Front / Back installation
Front / Back maintenance |
| 20 | Life Span | 100,000Hours |
Notices:
① Open the package, check the product carefully, and handle it with
care to avoid damaging the product.
② Be sure to connect the wires correctly, do not connect the wrong
wires.
③ Regularly inspect whether the anti-corrosion and anti-rust paint
on the surface of the product and steel structure welding points is
peeling off. If there is peeling or rust, spray anti-rust paint or
apply anti-rust paste in time.
④ The power supply should be stable, and the grounding protection
should be good. Regularly check the reliability of the lightning
rod and grounding system.
Application:
Widely used for outdoor squares, stadiums, hotels, hospitals,
schools, shopping malls, supermarkets, etc.
FAQ:
Q1. Can I have a sample order for led display?
A: Yes, we welcome sample order to test and check quality. Mixed
samples are acceptable.
Q2. What about the lead time?
A: 15-25 days for Sample preparing ,25-35 working days for mass
production.
Q3. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm
the design firstly based on our sample.
Q4. If I broad the market, can I be your agents?
A: Yes, we want to build relationship with all local powerful
distributor service is good for support you do long time local
service to win customer. Our price and quality can give our
customer more profit.
Q5. How to proceed an order for led display?
A: Firstly, let us know your requirements or application.
Secondly, We quote according to your requirements or our
suggestions.
Thirdly, customer confirms the samples and places deposit for
formal order.
Fourth, we arrange production and delivery.
